Binocular Indirect Ophthalmoscope

BIO200
Type: Head-mounted/Binocular Observation
Light Source: LED 3.3V/1.5A (5W)
Eyepiece 2D: Working Distance 500mm (from the cornea of the eye being examined to the light exit of the binocular indirect ophthalmoscope)
Interpupillary Distance Adjustment: 48mm to 76mm
Field of View Diameter: ≥160mm
Field of View Angle: 45° ± 5°
Maximum Illumination Spot Diameter: ≥60mm
Illumination Spot Vertical Adjustment Angle: ≥±4°
Headband Adjustment: 512mm to 642mm
Color Rendering Index: ≥93
Iris Adjustment: Large (60mm), Medium (40mm), Small (20mm)
Filter Adjustment: Cobalt Blue, Through-Hole, Red-Free (Green), Diffuse
Illumination Brightness: Steplessly Adjustable
Battery Indicator: Equipped with four battery indicators to indicate battery level

Consult

Features
Technical Indicators
Overall Dimension

Adopt imported LED light source, which has longer service life and brighter lighting brightness. Humanized headband design fits the examiner's head more comfortably. It is more convenient and clearer to examine patients with small pupils ≤ 2mm. Two working modes can be switched at will: charging battery (wireless mode) or connecting to AC power (wired mode). Ultra-light structure design reduces the examiner's fatigue.
Type Head-mounted/binocular Eyepiece ±2D (0D eyepiece is optional) Light source LED, 3500K, CRI ≥ 92 Lighting spot angle adjustment ±4° Lighting spot Large, medium, small (three types) Working distance 500mm Interpupillary distance adjustment 48~76mm Filter Cobalt blue film, red-free film, diffused film Aperture plate 20mm,40mm,60mm Rechargeable lithium battery DC3.7V/1000mAh/3.7Wh complies with IEC62133-2 standard Power adapter Input: 100-240~, 50/60Hz Output: 5.0V ⎓ 1.0A Main body size 290×210x170mm Main body weight 480g

Type	Head-mounted/binocular
Eyepiece	±2D (0D eyepiece is optional)
Light source	LED, 3500K, CRI ≥ 92
Lighting spot angle adjustment	±4°
Lighting spot	Large, medium, small (three types)
Working distance	500mm
Interpupillary distance adjustment	48~76mm
Filter	Cobalt blue film, red-free film, diffused film
Aperture plate	20mm,40mm,60mm
Rechargeable lithium battery	DC3.7V/1000mAh/3.7Wh complies with IEC62133-2 standard
Power adapter	Input: 100-240~, 50/60Hz Output: 5.0V ⎓ 1.0A
Main body size	290×210x170mm
Main body weight	480g
